技术参数

◎规格：端钮盒铜条，小A(7×9)、中A(9×11、10×12)、

  大A(11×13)

◎电流配置：三相四线1.5(6)A带10个辅助端口

                      三相四线10(40)A带10个辅助端口

                      三相四线20(100)A带10个辅助端口

                      另有三相三线小电流端口可选配

◎说明：采用最新国网标准拆分式端钮盒及塑料铅封设计，外观

    高端大气，另有复费率表型可供选择。

TECHNICAL PARAMETERS

◎Specifications: copper bar of terminal box, small A(7×9), middle A

    (9×11, 10×12), large A(11×13)

◎Current configuration: three-phase four-wire 1.5(6)A with 10 auxiliary ports

                        three-phase four-wire 10(40)A with 10 auxiliary ports

                        three-phase tour-wire 20(100)A with 10 auxiliary ports

                        three-phase three-wire with low current port is optional

◎Note: it designed by the latest standard split terminal box and plastic

    seal of state grid, the appearance is high-end and beautiful, there

    is also multi-rate meter for choice.
